YILKI ROAD FRAMES
Ready-made frames were created for customers who do not want to wait for the relatively long process of custom-made frames.
Ready made frames, which are delivered in a shorter time compared to custom-made frames, are also building with the same quailty and production methods.
In addition to the available colors, special colors and custom designs are also available with preorder
You can also order as a complete bicycle.
SPECS
Columbus Zona double/triple buttedCromoly tubes
Max tyre clearence : 35 mm
Standard T47 68mm bottom bracket
44 mm Columbus Spirit – HSS headtube
Full carbon tapered (1 1/2″ – 1 1/8″) flat mount Soulrider disc fork
Cane Creek 40 or Columbus Compass headset
Extra Options (valid for pre-orders)
Semi or fully internal cable route ( only for electronic shifting)
Custom design and painting.
-
YILKI READY MADE FRAMESET1.300,00 € – 1.600,00 € KDV hariç
GEOMETRİ
| Ölçüler | 50 | 52 | 54 | 56 | 58 | 60 | |
| A | Üst Boru Uzunluğu ( yatay) | 527 | 540 | 548 | 560 | 580 | 595 |
| B | Sele Borusu Uzunluğu (C-T) | 500 | 520 | 540 | 560 | 580 | 600 |
| C | Sele Borusu Açısı | 74,5° | 74° | 74° | 73,5° | 73,5° | 73° |
| D | Alın Borusu Açısı | 72° | 72,5° | 72,8° | 73° | 73,5° | 73,5° |
| E | Aks Aralığı | 979 | 983 | 990 | 997 | 1010 | 1028 |
| F | Alın Borusu Uzunluğu | 120 | 130 | 140 | 155 | 175 | 195 |
| G | Stack | 526 | 535 | 552 | 563 | 590 | 609 |
| H | Reach | 381 | 386 | 390 | 394 | 406 | 406 |
| J | Standover | 759 | 776 | 789 | 807 | 830 | 845 |
| K | Çeki borusu Uzunluğu | 408 | 408 | 410 | 410 | 410 | 415 |
| L | Ön – Merkez Mesafesi | 580 | 584 | 590 | 595 | 611 | 620 |
| M | Orta Göbek Yüksekliği | 70 | 70 | 70 | 70 | 70 | 70 |
| N | Trail | 64 | 61 | 58 | 58 | 56 | 56 |
| R | Rake | 45 | 45 | 45 | 45 | 45 | 45 |
